MultiQuantityGPs

This module contains everything to do with what is inferred about values in the environment. In practical terms: means, variances, and correlations. This is all built on Gaussian Processes.

Main public types and functions:

• MQGP
• MQSample
• SQSample
• fullCov
• getLoc
• getObs
• getQuant
• meanDerivAndVar
• quantityCorMat
• quantityCovMat

struct NamedTuple{(:lower, :upper), Tuple{Vector{Float64}, Vector{Float64}}}

The bounds of the region. Consists of the lower and upper bounds, each a list of floating-point values.

A multivariate linear model of $y$ dependent on $x$ with parameters $a$ and $b$ of the form

\[Y = a + b^T X\]

X and Y are matrices containing the points as columns.

Returns a linear model of set of variables Y conditioned on set X. Requires full mean vector and covariance matrix of the joint normal distribution.

mutable struct Array{Float64, 1} <: DenseVector{Float64}

Location of sample

struct MQGP{T}

Belief model struct and function for multiple quantities with 2D inputs.

Designed on top of a Multi-Quantity Gaussian Process, but can still be used with a single quantity.

Its interface: X -> μ, σ (SampleInputs -> means, standard deviations)

MQGP(
    samples::AbstractArray{<:@NamedTuple{x::Tuple{Vector{Float64}, Int64}, y::Float64}};
    bounds,
    N,
    kernel,
    means_use,
    means_learn,
    noise_value,
    noise_learn,
    use_cond_pdf
) -> MQGP{typeof(MultiQuantityGPs.Kernels.multiKernel)}

Creates and returns a MQGP with hyperparameters trained and conditioned on the samples given. Lower and upper bounds are used to initialize one of the hyperparameters.

A noise standard deviation can optionally be passed in either as a single scalar value for all samples or a vector of values, one for each sample.

Examples

# create a MQGP
beliefModel = MQGP([prior_samples; samples]; bounds)

Inputs:

• X: a single sample input or an array of multiple
• full_cov: (optional) if this is true, returns the full covariance matrix in place of the vector of standard deviations

Outputs:

• μ, σ: a pair of expected value(s) and uncertainty(s) for the given point(s)

Examples

X = [([.1, .2], 1),
     ([.2, .1], 2)]
μ, σ = beliefModel(X) # result: [μ1, μ2], [σ1, σ2]

struct NamedTuple{(:x, :y), Tuple{Tuple{Vector{Float64}, Int64}, Float64}}

Type of sample measurement with noise, the measurement mean and standard deviation

struct Tuple{Vector{Float64}, Int64}

Multi-quantity sample input, the combination of: (Location, quantity index)

struct Tuple{Float64, Float64}

Type of sample measurement with noise, the measurement mean and standard deviation

struct NamedTuple{(:x, :y), Tuple{Vector{Float64}, Float64}}

Type of sample measurement with noise, the measurement mean and standard deviation

primitive type Float64 <: AbstractFloat 64

Type of noise-free sample measurement

createLossFunc(
    X,
    Y_vals,
    Y_errs,
    kernel,
    use_cond_pdf
) -> MultiQuantityGPs.var"#12#13"

This function creates the loss function for training the GP. The negative log marginal likelihood is used.

fullCov(
    bm::MQGP,
    X::AbstractArray{Tuple{Vector{Float64}, Int64}}
) -> Any

Returns the full covariance matrix for the belief model.

getLoc(
    s::@NamedTuple{x::Tuple{Vector{Float64}, Int64}, y::Float64}
) -> Vector{Float64}

Get the location for the sample.

getLoc(
    s::@NamedTuple{x::Vector{Float64}, y::Float64}
) -> Vector{Float64}

Get the location for the sample.

getObs(
    s::@NamedTuple{x::Tuple{Vector{Float64}, Int64}, y::Float64}
) -> Float64

Get the observation for the sample.

getObs(
    s::@NamedTuple{x::Vector{Float64}, y::Float64}
) -> Float64

Get the observation for the sample.

getQuant(
    s::@NamedTuple{x::Tuple{Vector{Float64}, Int64}, y::Float64}
) -> Int64

Get the quantity for the sample.

latentCovMat(
    bm::MQGP{typeof(MultiQuantityGPs.Kernels.multiKernel)}
) -> Any

Gives the covariance matrix between all latent functions from the hyperparameters.

meanDerivAndVar(
    bm::MQGP,
    x::Tuple{Vector{Float64}, Int64}
) -> Tuple{Any, Any}

Returns the normed gradient of the mean of the belief model and its variance.

optimizeLoss(lossFunc, θ0; solver, iterations) -> Any

Routine to optimize the lossFunc and return the optimal parameters θ.

Can pass in a different solver. NelderMead is picked as default for better speed with about the same performance as LFBGS.

quantityCorMat(beliefModel::MQGP)

Gives the correlation matrix between all quantities from the hyperparameters.

quantityCovMat(bm::MQGP) -> Any

Gives the covariance matrix between all quantities from the hyperparameters. The model of the quantities is the latent functions plus their measurement noise.

SLFMMOKernel(g::AbstractVector{<:Kernel}, A::AbstractMatrix)

Kernel associated with the semiparametric latent factor model.

Definition

For inputs $x, x'$ and output dimensions $p, p''$, the kernel is defined as

\[k\big((x, p), (x', p')\big) = \sum^{Q}_{q=1} A_{p q}g_q(x, x')A_{p' q},\]

where $g_1, \ldots, g_Q$ are $Q$ kernels, one for each latent process, and $A$ is a matrix of weights for the kernels of size $m \times Q$.

customKernel(
    θ
) -> MultiQuantityGPs.Kernels.CustomMOKernel{_A, <:AbstractMatrix{T}} where {_A, T}

Creates a custom kernel function for the GP similar to the slfmKernel but with matrices of length-scales and amplitudes.

This one does not work and is likely not theoretically valid.

fullyConnectedCovMat(a) -> Any

Creates an output covariance matrix from an array of parameters by filling a lower triangular matrix.

Inputs:

• a: parameter vector, must hold (N+1)*N/2 parameters, where N = number of outputs

fullyConnectedCovNum(num_outputs) -> Any

Gives the number of hyperparameters for to fill the fullyConnectedCovMat.

initHyperparams(
    X,
    Y_vals,
    bounds,
    N,
    ::typeof(MultiQuantityGPs.Kernels.mtoKernel);
    kwargs...
) -> NamedTuple{(:σ, :ℓ), <:Tuple{Any, Any}}

Creates the structure of hyperparameters for a MTGP and gives them initial values. This is for a specialized quantity covariance matrix with separation.

initHyperparams(
    X,
    Y_vals,
    bounds,
    N,
    ::typeof(MultiQuantityGPs.Kernels.multiKernel);
    kwargs...
) -> NamedTuple{(:σ, :ℓ), <:Tuple{Any, Any}}

Creates the structure of hyperparameters for a MTGP and gives them initial values.

initHyperparams(
    X,
    Y_vals,
    bounds,
    N,
    ::typeof(MultiQuantityGPs.Kernels.slfmKernel);
    kwargs...
) -> NamedTuple{(:σ, :ℓ), <:Tuple{Any, Any}}

Creates the structure of hyperparameters for a SLFM and gives them initial values.

manyToOneCovMat(a) -> Any

Creates an output covariance matrix from an array of parameters by filling the first column and diagonal of a lower triangular matrix.

Inputs:

• a: parameter vector, must hold 2N-1 parameters, where N = number of outputs

manyToOneCovNum(num_outputs) -> Any

Gives the number of hyperparameters for to fill the manyToOneCovMat.

mtoKernel(θ) -> KernelFunctions.IntrinsicCoregionMOKernel

Creates a kernel function for the GP, which is similar to a multiKernel but instead uses a many-to-one quantity covariance matrix.

multiKernel(θ) -> KernelFunctions.IntrinsicCoregionMOKernel

A multi-task GP kernel, a variety of multi-output GP kernel based on the Intrinsic Coregionalization Model with a Squared Exponential base kernel and an output matrix formed from a lower triangular matrix.

This function creates the kernel function used within the GP.

multiMean(
    θ
) -> AbstractGPs.CustomMean{Tf} where Tf<:MultiQuantityGPs.Kernels.var"#13#14"

Creates a quantity-specific constant mean function from the GP hyperparameters.

singleKernel(θ) -> Any

A simple squared exponential kernel for the GP with parameters θ.

This function creates the kernel function used within the GP.

slfmKernel(
    θ
) -> MultiQuantityGPs.Kernels.SLFMMOKernel{_A, <:AbstractMatrix{T}} where {_A, T}

Creates a semi-parametric latent factor model (SLFM) kernel function for the GP.
